Damen Shoalbuster 3511 'DMS Osprey'

Shoalbuster 'DMS Osprey'

70.9

35.25

11.60

11.6

Available for charter multi-functional vessel for areas of limited manoeuvrability in shallow and deep waters.


Specifications

Delivery date
2010
Classification
Bureau Veritas
Flag
Dutch
Bollard pull ahead
70,9 t
Speed
11.6 kts
Beam overall
11.60 m
Draught
4,4 m
Deckspace
90,65 m²
Displacement
n/a
Fuel oil
374.4 m³
Fresh water
42.0 m³
Main engines
2x Caterpillar, type 3516 B TA
Total power
3840 kW (5150 hp) at 1600 rpm
Propulsion
2x fixed pitch propellers in nozzles
Genset
Leroy Somer, type LSAM 46.2 M5
Deck equipment
Deck crane: Heila 170-4S-L, remote controlled, Capacity: 18,2 tons at 8,03 m 7,9 tons at 15,93 m Tugger winch: Brevini, 8 tons at 4.5 m/min. Towing pins: Karm Fork, 160 tons SWL Towing wire storage reel: Electrical driven, 500 m x 48 mm wire Stern roller: 5000 mm x 980 mm, 100 tons SWL
Nautical equipment
All systems and equipment according to GMDSS Area 3
Accommodation
Heated and air-conditioned living spaces for 15 persons

Gallery
