A Trailing Suction Pipe system is key to efficient hopper loading. The dredge pipe, hoisted overboard using dedicated gantries and winches, is integrated in your hopper dredger seamlessly. The tailor-made dredge package ensures a complete delivery, whereas the shipyard can focus on the vessel itself. Our technical support ensures a perfect fit. Our first-class dredging components are built to last, maximising uptime and minimising maintenance duties. Our proven concept ensures a fit-for-purpose design, in keeping with the harsh dredging environment.
- Dredge valves
- Dredge pumps
- Bow coupling units
- Dredging instrumentation
- Flow optimised drag head design
- Suitable for various soil types
- Barge conversion made easy
- Heavy duty design with replaceable wear parts
Key figures
500
20
3550
1000
Dimensions
- Dredge pipe diameter
- 500 m
- Dredge pump
- BP5045LD
- Max wave height
- 2 m
Capacities
- Pump capacity
- 3550 m³/h
- Hopper capacity
- 1000 m³
- Loading time
- 20 minutes
Dredging depth
- Minimum depth
- - 7.5 m
- Average depth
- - 20 m
- Maximum depth
- - 35 m
Do you want to know more?
Compare similar suction pipe systems
| Dredge pipe diameter (mm) | Av dredging depth (m) | Mixture capacity (m³/h) | Hopper capacity (m³) | ||
|---|---|---|---|---|---|
| Trailing Suction Pipe TSP500 | 500 | 20 | 3550 | 1000 | |
| Trailing Suction Pipe TSP400 | 400 | 15 | 2250 | 500 | |
| Trailing Suction Pipe TSP600 | 600 | 20 | 5100 | 1500 |
